MS2410 Electromagnetic Flowmeter

Reliable, High Accuracy Flowmeter for Food, Beverage and Pharmaceutical Applications.

Flomotion Systems  Model 501 Electromagnetic FlowmeterModel HS300 Electromagnetic Batching Flowmeter

MS2410
  • Accuracy to ±0.2% of rate from 3 to 33 ft/sec.
  • Ten sizes from 1/8" to 4" pipe diameters.
  • Flow ranges from 0.034 to 1246 GPM.
  • Standard Pressure: 230 PSI.
  • Volumetric flow rate measurement independent of fluid viscosity, density and temperature.
  • Bi-directional flow measurement.
  • No moving parts for zero maintenance.
  • No pressure drop through sensor.
  • Minimal straight pipe run required.
  • Every sensor is factory wet-calibrated.
  • Rated for 3A sanitary approval.
  • Suitable for vacuum service applications.



    FIND OUT MORE

TYPICAL INDUSTRY PRODUCT APPLICATIONS

  • Cosmetics
  • Juices
  • Ketchup
  • Milks
  • Yogurt
  • Water
  • Wines
  • Flavorings
  • Soups
  • Ice Cream Mixes


SENSOR SIZES AND CAPACITIES

Sensor Size
1/8"
1/4"
3/8"
1/2"
3/4"
1"
1.5"
2"
3"
4"
Minimum flow rate
(GPM @ 1 ft/sec)
0.034
0.14
0.38
0.85
1.52
2.37
6.08
9.49
24.30
37.97
Maximum flow rate
(GPM @ 33 ft/sec)
181.9
323.4
727.65
1293.6
2910
77.9
199.3
311.5
797.4
1246
